The Solis-AlphaESS SMILE-BAT-13.3P is a high-performance lithium iron phosphate (LiFePO4) energy storage system designed for residential and commercial applications. It provides 13.3kWh of storage capacity with long cycle life, high efficiency, and safe IP65-rated outdoor installation capability.
| Performance Parameters | |
|---|---|
| Model | Solis-AlphaESS SMILE-BAT-13.3P |
| Battery Type | EVE – LiFePO4 (Lithium Iron Phosphate) |
| Nominal Battery Energy | 13.3 kWh |
| Operating Voltage | 45 ~ 54 Vdc |
| Nominal Voltage | 48 V |
| Nominal Capacity | 280 Ah |
| Rated Power | 13.34 kW |
| Peak Power | 5 kW |
| Recommended Charge/Discharge C-Rate | 0.35 C |
| Recommended Charge/Discharge Current | 100 A |
| Depath of Discharge (DoD) | 100% |
| General Information | |
| Net Weight | 121 kg |
| Dimensions (W × H × D) | 610 × 816 × 236 mm |
| Charging Temperature Range | -10°C ~ 50°C |
| Discharging Temperature Range | -10°C ~ 50°C |
| Communication | CAN / RS-485 |
| Cycle Life | 8000 Cycles / 10 Years |
| Protection Rating | IP65 |
| Expansion Capability | Supports up to 6 units in parallel |
| Installation Mode | Floor or Wall-Mounted |
| Certifications | UN38.3 / IEC62619 |
Recommended Applications: Residential backup storage, off-grid integration, solar hybrid systems, energy cost optimization.
Please note: Packaging contents depend on the purchased battery package:
Package 1:
Package 2:
