Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 9.9kW Single Phase Hybrid Inverter (SOL-S6-GR1P9.9K03-NV-ND-AU)
Description The Solis S6-GR1P9.9K03-NV-ND-AU is a 9.9kW single-phase grid-tied inverter from the S6 series, designed for residential and commercial PV systems. It is not a hybrid inverter and does not have battery communication ports...
Vendor:
Ople Appliances
Availability:
In Stock
- $6,699.00
- $6,699.00
- Unit price
- per
10 customers are viewing this product
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 9.9kW Single Phase Hybrid Inverter (SOL-S6-GR1P9.9K03-NV-ND-AU)
$6,699.00
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 9.9kW Single Phase Hybrid Inverter (SOL-S6-GR1P9.9K03-NV-ND-AU)
$6,699.00
Description
xDescription
The Solis S6-GR1P9.9K03-NV-ND-AU is a 9.9kW single-phase grid-tied inverter from the S6 series, designed for residential and commercial PV systems. It is not a hybrid inverter and does not have battery communication ports for direct energy storage integration.
The Dyness Powerbox Pro is a 10.24kWh low-voltage battery designed for residential energy storage systems.
⚠️ Important Compatibility Note: The S6-GR1P9.9K03-NV-ND-AU is a grid-tied inverter, NOT a hybrid inverter. It cannot directly connect to or manage a battery. To use the Powerbox Pro battery for energy storage, you need a hybrid inverter. These two products are not directly compatible as a combined storage system.
Key Features
Inverter - S6-GR1P9.9K03-NV-ND-AU (Grid-Tied Only)
-
9.9kW single-phase output power
-
Three MPPT trackers for complex rooftop applications
-
20A string current capability, compatible with high-power solar modules
-
IP66 protection rating for outdoor installation
-
Bluetooth setup, control, and monitoring via smartphone app
-
AFCI arc fault protection to reduce fire risk
-
Remote firmware updates via SolisCloud
Battery - Powerbox Pro (10.24kWh)
-
10.24kWh nominal energy capacity
-
Safe LiFePO₄ (Lithium Iron Phosphate) battery chemistry
-
Built-in advanced Battery Management System (BMS)
-
Recommended 85-90% depth of discharge
-
Wall or floor mount options included
Specifications
S6-GR1P9.9K03-NV-ND-AU Inverter Specifications (Grid-Tied)
| Parameter | Specification | Source |
|---|---|---|
| Model | S6-GR1P9.9K03-NV-ND-AU | Based on available information |
| Rated Output Power | 9,900 W (9.9kW) | Based on model number |
| Phase Support | Single Phase | Based on model number |
| Grid Support | On-Grid (Grid-Tied) | Based on model number |
| Protection Rating | IP66 | Standard for S6-GR series |
| DC/AC Ratio | >150% | Standard for S6-GR series |
Powerbox Pro Battery Specifications
| Parameter | Specification |
|---|---|
| Product Model | Powerbox Pro |
| Nominal Energy | 10.24 kWh |
| Nominal Capacity | 200 Ah |
| Nominal Voltage | 51.2 V |
| Operating Voltage Range | 44.8 - 57.6 V |
| Battery Type | LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Power | 5.12 kW |
| Peak Power | 10.24 kW |
| Recommended Charge/Discharge Current | 100 A |
| Recommended C-Rate | 0.5 C |
| Recommended Depth of Discharge | 85-90% |
| Cycle Life | ≥6,000 cycles |
| Operating Temperature (Discharge) | -20°C ~ 55°C |
| Operating Temperature (Charge) | 0°C ~ 55°C |
| Protection Rating | IP65 |
| Communication Interfaces | CAN, RS485, RS232 |
| Dimensions (W × D × H) | 555 × 210 × 928 mm |
| Weight | 99.3-103 kg |
| Maximum Parallel Units | Up to 50 units (512kWh) |
| Certifications | CEC, CE, EMC, RCM, UN38.3, IEC |
