Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 5kW Three Phase Hybrid Inverter (SOL-S6-GR3P5K03-NV-ND-AU)
Description The Solis S6-GR3P5K03-NV-ND-AU is a 5kW three-phase grid-tied inverter from the S6 series, designed for residential and commercial PV systems. It is not a hybrid inverter and does not have battery communication ports...
Vendor:
Ople Appliances
Availability:
In Stock
- $6,299.00
- $6,299.00
- Unit price
- per
10 customers are viewing this product
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 5kW Three Phase Hybrid Inverter (SOL-S6-GR3P5K03-NV-ND-AU)
$6,299.00
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 5kW Three Phase Hybrid Inverter (SOL-S6-GR3P5K03-NV-ND-AU)
$6,299.00
Description
xDescription
The Solis S6-GR3P5K03-NV-ND-AU is a 5kW three-phase grid-tied inverter from the S6 series, designed for residential and commercial PV systems. It is not a hybrid inverter and does not have battery communication ports for direct energy storage integration .
The Dyness Powerbox Pro is a 10.24kWh low-voltage battery designed for residential energy storage systems .
⚠️ Important Compatibility Note: The S6-GR3P5K03-NV-ND-AU is a grid-tied inverter, NOT a hybrid inverter. It cannot directly connect to or manage a battery. To use the Powerbox Pro battery for energy storage, you need a hybrid inverter. These two products are not directly compatible as a combined storage system.
Key Features
Inverter - S6-GR3P5K03-NV-ND-AU (Grid-Tied Only)
-
5kW three-phase output power
-
3 MPPT trackers for complex rooftop applications
-
20A string current capability, compatible with high-power solar modules
-
DC/AC ratio greater than 150%
-
IP66 protection rating for outdoor installation
-
Bluetooth setup, control, and monitoring via smartphone app
-
AFCI arc fault protection to reduce fire risk
-
Remote firmware updates via SolisCloud
-
10-year product warranty
Battery - Powerbox Pro (10.24kWh)
-
10.24kWh nominal energy capacity
-
Safe LiFePO₄ battery chemistry
-
Built-in advanced Battery Management System (BMS)
-
Recommended 85-90% depth of discharge
-
Up to 50 units in parallel (max 512kWh)
-
Wall or floor mount options
-
IP65 rated enclosure for indoor or outdoor installation
Specifications
S6-GR3P5K03-NV-ND-AU Inverter Specifications (Grid-Tied)
| Parameter | Specification |
|---|---|
| Model | S6-GR3P5K03-NV-ND-AU |
| Rated Output Power | 5,000 W (5kW) |
| Phase Support | Three Phase |
| Grid Support | On-Grid |
| Number of MPPTs | 3 |
| Number of Strings | 1 per MPPT (3 total) |
| Max String Current | 20A |
| DC/AC Ratio | >150% |
| Protection Rating | IP66 |
| Dimensions (W×H×D) | 355 × 410 × 179 mm |
| Weight | 14.7 kg |
| Product Warranty | 10 Years |
Powerbox Pro Battery Specifications
| Parameter | Specification |
|---|---|
| Product Model | Powerbox Pro |
| Nominal Energy | 10.24 kWh |
| Nominal Capacity | 200 Ah |
| Nominal Voltage | 51.2 V |
| Operating Voltage Range | 44.8 - 57.6 V |
| Battery Type | LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Power | 5.12 kW |
| Peak Power | 10.24 kW |
| Recommended Charge/Discharge Current | 100 A |
| Recommended C-Rate | 0.5 C |
| Recommended Depth of Discharge | 90% |
| Cycle Life | ≥6,000 cycles |
| Operating Temperature (Discharge) | -20°C ~ 55°C |
| Protection Rating | IP65 |
| Communication Interfaces | CAN, RS485, RS232 |
| Dimensions (W × D × H) | 555 × 210 × 928 mm |
| Weight | 99.3-103 kg |
| Maximum Parallel Units | Up to 50 units (512kWh) |
