Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 5kW Single Phase Hybrid Inverter (SOL-S6-GR1P5K-S-v3)
Description The Solis S6-GR1P5K-S-v3 is a 5kW single-phase grid-tied inverter designed for residential PV systems. It is not a hybrid inverter and does not have battery communication ports for direct energy storage integration . The...
Vendor:
Ople Appliances
Availability:
In Stock
- $6,199.00
- $6,199.00
- Unit price
- per
10 customers are viewing this product
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 5kW Single Phase Hybrid Inverter (SOL-S6-GR1P5K-S-v3)
$6,199.00
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 5kW Single Phase Hybrid Inverter (SOL-S6-GR1P5K-S-v3)
$6,199.00
Description
xDescription
The Solis S6-GR1P5K-S-v3 is a 5kW single-phase grid-tied inverter designed for residential PV systems. It is not a hybrid inverter and does not have battery communication ports for direct energy storage integration .
The Dyness Powerbox Pro is a 10.24kWh low-voltage battery designed for residential energy storage systems.
⚠️ Important Compatibility Note: The S6-GR1P5K-S-v3 is a grid-tied inverter, NOT a hybrid inverter. It cannot directly connect to or manage a battery. To use the Powerbox Pro battery for energy storage, you need a hybrid inverter (e.g., Solis S6-EH1P series or other hybrid models). These two products are not directly compatible as a combined storage system.
Key Features
Inverter - S6-GR1P5K-S-v3 (Grid-Tied Only)
-
5kW rated output power
-
14A input current per MPPT (compatible with high-power PV modules)
-
Natural convection cooling - fanless, quiet operation (<20 dBA)
-
Integrated DC switch
Battery - Powerbox Pro (10.24kWh)
-
10.24kWh nominal energy capacity
-
Safe LiFePO₄ (Lithium Iron Phosphate) battery chemistry
-
Built-in advanced Battery Management System (BMS)
-
Recommended 85-90% depth of discharge
-
Up to 5 units in parallel (max 51.2kWh)
-
Wall or floor mount options (mounting kit included)
-
IP65 rated enclosure for indoor or outdoor installation
Specifications
S6-GR1P5K-S Inverter Specifications (Grid-Tied)
AC Output Parameters
| Parameter | Specification |
|---|---|
| Rated Output Power | 5,000 W (5kW) |
| Max Output Power | 5,500 W |
| Max Apparent Output Power | 5,500 VA |
| Number of Phases | Single Phase (1/N/PE) |
| Rated Grid Voltage | 220V/230V |
| Rated Output Current | 22.7A (230V) / 21.7A (220V) |
| Max Output Current | 24A |
| Power Factor | >0.99 (0.8 leading - 0.8 lagging) |
| THDi | <3% |
| Rated Grid Frequency | 50/60 Hz |
| Operating Frequency Range | 45-55 Hz or 55-65 Hz |
DC Input (PV Side) Parameters
| Parameter | Specification |
|---|---|
| Max DC Input Voltage | 550 V |
| Rated DC Voltage | 250 V |
| Startup Voltage | 60 V |
| MPPT Voltage Range | 50 - 450 V |
| Number of MPPT Trackers | 2 |
| Number of String Inputs | 2 |
| Max Input Current per MPPT | 14 A |
| Max Short Circuit Current per MPPT | 22 A |
Efficiency Parameters
| Parameter | Specification |
|---|---|
| Maximum Efficiency | 97.3% |
| European Efficiency | 96.5% |
Protection & General Data
| Parameter | Specification |
|---|---|
| Protection Rating | IP66 |
| Dimensions (W × H × D) | 310 × 543 × 160 mm |
| Weight | 11 kg |
| Cooling Method | Natural convection (fanless) |
| Noise Emission | <20 dBA |
| Operating Temperature Range | -25°C ~ +60°C |
| Relative Humidity | 0-100% |
| Max Operating Altitude | 4000 m |
| Topology | Transformerless |
| Self Consumption (night) | <1 W |
| DC Connection | MC4 connector |
| AC Connection | Quick connection plug |
| Display | LCD, 2×20 Z |
| Communication Interfaces | RS485; Optional: Wi-Fi, GPRS |
| Warranty | 5 years (extendable to 20 years) |
Powerbox Pro Battery Specifications
| Parameter | Specification |
|---|---|
| Nominal Energy | 10.24 kWh |
| Nominal Capacity | 200 Ah |
| Nominal Voltage | 51.2 V |
| Operating Voltage Range | 44.8 - 57.6 V |
| Battery Type | LiFePO₄ (Lithium Iron Phosphate) |
| Cell Type | Prismatic |
| Nominal Power | 5.12 kW |
| Peak Power | 10.24 kW |
| Max Continuous Charge/Discharge Current | 100 A |
| Recommended C-Rate | 0.5C |
| Recommended Depth of Discharge | 85-90% |
| Cycle Life | ≥6,000 cycles |
| Operating Temperature (Charge) | 0°C ~ 55°C |
| Operating Temperature (Discharge) | -20°C ~ 55°C |
| Protection Rating | IP65 |
| Communication Interfaces | CAN, RS485, RS232 |
| Dimensions (W × D × H) | 555 × 210 × 928 mm |
| Weight | 99.3-103 kg |
| Maximum Parallel Units | Up to 5 (51.2kWh) |
