Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 3kW Single Phase Hybrid Inverter (SOL-S6-GR1P3K-S)
Description The Solis S6-GR1P3K-S is a 3kW single-phase grid-tied inverter designed for residential PV systems. It is not a hybrid inverter and does not support battery energy storage on its own . The Dyness Powerbox...
Vendor:
Ople Appliances
Availability:
In Stock
- $6,199.00
- $6,199.00
- Unit price
- per
10 customers are viewing this product
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 3kW Single Phase Hybrid Inverter (SOL-S6-GR1P3K-S)
$6,199.00
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 3kW Single Phase Hybrid Inverter (SOL-S6-GR1P3K-S)
$6,199.00
Description
xDescription
The Solis S6-GR1P3K-S is a 3kW single-phase grid-tied inverter designed for residential PV systems. It is not a hybrid inverter and does not support battery energy storage on its own .
The Dyness Powerbox Pro is a 10.24kWh low-voltage battery designed for residential energy storage .
⚠️ Important Compatibility Note: The S6-GR1P3K-S is a grid-tied inverter without battery communication ports. To use this battery, you need a hybrid inverter (e.g., Solis S6-EH1P series) that can manage battery charging/discharging. These two products are not directly compatible as a combined system.
Key Features
Inverter - S6-GR1P3K-S (Grid-Tied Only)
Battery - Powerbox Pro (10.24kWh)
-
10.24kWh nominal energy capacity
-
Built-in advanced Battery Management System (BMS)
Specifications
S6-GR1P3K-S Inverter Specifications (Grid-Tied)
| Parameter | Specification |
|---|---|
| Rated AC Output Power | 3,000 W (3kW) |
| Max Apparent Output Power | 3,000 VA |
| Rated Output Current | 13.6 A (230V) / 13 A (220V) |
| Number of Phases | Single Phase (1/N/PE) |
| Rated Grid Voltage | 220V / 230V |
| Rated Grid Frequency | 50 Hz |
DC Input (PV Side)
| Parameter | Specification |
|---|---|
| Recommended Max PV Power | 4,500 W (4.5kW) |
| Max DC Input Voltage | 550 V |
| Rated Voltage | 330 V |
| Start-up Voltage | 100 V |
| MPPT Voltage Range | 90 - 550 V |
| Number of MPPT Trackers | 2 |
| Number of String Inputs | 2 |
| Max Input Current per MPPT | 16 A |
| Max Short Circuit Current per MPPT | 22 A |
Efficiency
| Parameter | Specification |
|---|---|
| Maximum Efficiency | 97.3% |
| European Efficiency | 96.6% |
Protection & General
| Parameter | Specification |
|---|---|
| Protection Rating | IP66 |
| Dimensions (W×H×D) | 330 × 371 × 161 mm |
| Weight | 8.2 kg |
| Cooling Method | Natural convection |
| Operating Temperature | -25°C ~ +60°C |
| Max Operating Altitude | 4000 m |
| Topology | Transformerless |
| Self Consumption (night) | <1 W |
| DC Switch | Integrated |
| AFCI Protection | Yes (activation required) |
Powerbox Pro Battery Specifications
| Parameter | Specification |
|---|---|
| Product Model | Powerbox Pro |
| Nominal Battery Energy | 10.24 kWh |
| Nominal Capacity | 200 Ah |
| Nominal Voltage | 51.2 V |
| Operating Voltage Range | 44.8 - 57.6 V |
| Battery Type | LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Power | 5.12 kW |
| Peak Power | 10.24 kW |
| Recommended C-Rate | 0.5C |
| Max Continuous Charge/Discharge Current | 100 A |
| Recommended Depth of Discharge | 85-90% |
| Cycle Life | ≥6,000 cycles |
| Operating Temperature (Charge) | 0°C ~ 55°C |
| Operating Temperature (Discharge) | -20°C ~ 55°C |
| Protection Rating | IP65 |
| Communication Interfaces | CAN, RS485, RS232 |
| Dimensions (W × D × H) | 555 × 210 × 928 mm |
| Weight | 99.3-103 kg |
| Maximum Parallel Units | Up to 5 (51.2kWh) |
