Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 3kW Single Phase Hybrid Inverter (SOL-S5-GR1P3K-M)
Description The Solis S5-GR1P3K-M is a 3kW single-phase grid-tied inverter from the S5 Mini Series, designed for residential PV systems. It is not a hybrid inverter and does not have battery communication ports for...
Vendor:
Ople Appliances
Availability:
In Stock
- $6,099.00
- $6,099.00
- Unit price
- per
10 customers are viewing this product
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 3kW Single Phase Hybrid Inverter (SOL-S5-GR1P3K-M)
$6,099.00
Vendor: Ople Appliances
Solis 10.24kWh Dyness Powerbox Pro Energy Storage & 3kW Single Phase Hybrid Inverter (SOL-S5-GR1P3K-M)
$6,099.00
Description
xDescription
The Solis S5-GR1P3K-M is a 3kW single-phase grid-tied inverter from the S5 Mini Series, designed for residential PV systems. It is not a hybrid inverter and does not have battery communication ports for direct energy storage integration .
The Dyness Powerbox Pro is a 10.24kWh low-voltage battery designed for residential energy storage systems .
⚠️ Important Compatibility Note: The S5-GR1P3K-M is a grid-tied inverter, NOT a hybrid inverter. It cannot directly connect to or manage a battery. To use the Powerbox Pro battery for energy storage, you need a hybrid inverter (e.g., Solis S6-EH1P series). These two products are not directly compatible as a combined storage system.
Key Features
Inverter - S5-GR1P3K-M (Grid-Tied Only)
Battery - Powerbox Pro (10.24kWh)
-
Built-in advanced Battery Management System (BMS)
Specifications
S5-GR1P3K-M Inverter Specifications (Grid-Tied)
| Parameter | Specification |
|---|---|
| Model | S5-GR1P3K-M |
| Rated Output Power | 3,000 W (3kW) |
| Max Generator Power | 4,000 Wp |
| Number of Phases | Single Phase |
| Max Output Current | 15.7 A |
| Nominal AC Voltage | 330 V |
| Maximum Efficiency | 97.1% |
| Degree of Protection | IP65 |
| Operating Temperature Range | -25°C ~ +60°C |
| Night-time Consumption | <1 W |
| Cooling Method | Passive/Natural Air Cooling |
| Dimensions (W × H × D) | 310 × 373 × 160 mm |
| Weight | 7.7 kg |
| Communication Interfaces | Ethernet, WLAN, RS485 |
| Warranty | 5 years |
Powerbox Pro Battery Specifications
| Parameter | Specification |
|---|---|
| Nominal Energy | 10.24 kWh |
| Nominal Capacity | 200 Ah |
| Nominal Voltage | 51.2 V |
| Operating Voltage Range | 44.8 - 57.6 V |
| Battery Type | LiFePO₄ (Lithium Iron Phosphate) |
| Cell Type | Prismatic |
| Nominal Power | 5.12 kW |
| Peak Power | 10.24 kW |
| Max Continuous Charge/Discharge Current | 100 A |
| Recommended C-Rate | 0.5 C |
| Recommended Depth of Discharge | 90% |
| Cycle Life | ≥6,000 cycles |
| Operating Temperature (Charge) | 0°C ~ 55°C |
| Operating Temperature (Discharge) | -20°C ~ 55°C |
| Protection Rating | IP65 |
| Communication Interfaces | CAN, RS485, RS232 |
| Dimensions (W × D × H) | 555 × 210 × 928 mm |
| Weight | 99.3-103 kg |
| Maximum Parallel Units | Up to 5 (51.2kWh) |
